WORKING DRAWINGS

June 4, 2026

Working Drawings are drawings of the whole or part of a structure, made to a scale, and intended to be understood by the Contractor and followed by the workmen at site.

• Site Plan indicating setbacks and position of building, existing levels and intended new levels.
• Excavation, Foundation and Centre line Drawings indicating excavation pit sizes, column positions, dimensions, centre line distances, etc.
• Detailed Floor Plans of all the floors indicating all the dimensions – walls, rooms, columns, lifts and staircases etc. as well as the floor levels.
• Detailed Elevations indicating the levels of the floors and the heights. Any elevational treatment elements will be explained with additional drawings.
• Detailed Sections wherever necessary to explain the different levels and heights within the building, and to explain staircases, lift heights.
• Detailed Staircase drawings and Lift drawings.
• Door and Window Drawings indicating material used and the section sizes. If there are grills on the windows, the grill design drawings are also included.
